Name: 12VDC Input PWM 010V Dimmable Rod Antenna Daylight Sensor IP 20
Brand: HIASEN
Price: 1 USD

Brand Name : HIASEN

Model Number : HD013VR

Certification : CE RoHS

Place of Origin : China

MOQ : 100pcs

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100000pcs per month

Delivery Time : 1-3 days for sample order, 1-2 weeks for bulk order

Packaging Details : Bubble pack, paper flat, outer carton

Output : PWM/0-10V

Detection area : 25%/50%/75%/100%

Microwave frequency : 5.8GHz±75MHz

Operating temperature : -25°C~+60°C

Control : Remote control

Life time : 50000h

Contact Now

12VDC Input PWM 0-10V Dimmable Rod Antenna Daylight Sensor IP 20

Features:

Specifciation

Safety & EMC	Approval	CE, ROHS
Sensor Parameters	Detection angle	30°-150°
	Detection Area	25%/50%/75%/100%
	Hold time	5s/30s/1min/3min/5min/10min/20min/30min
	Daylight threshold	2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/ Disable
	Stand-by period	0S/10s/30s/1min/5min/10min/30min/+∞
	Stand-by dimming level	10%/20%/30%/50%
	Mounting Height	Max.2.5-4m/8.2-13.12ft
	Detection range	(Radius) 2-4m/6.56-13.12ft
	Operating temperature	-25°C~+60°C
Wireless Parameters	Operating Frequency	5.8GHz±75MHz
Wireless Parameters	Output	PWM/0-10V
Input	Operating voltage	10-15VDC
Input	Operating current	≥30mA
Others	Packaging Requirement	Bubble pack, paper flat, outer carton.
	Installation	Installed inside lamps
	Warranty	5 years
	IP rating	IP 20
	Life time	50000h
